KSP series are mature and widely‑used quick‑disconnect connectors. Male and female ends are locked by push‑buttons for easy operation, with a broad range of tubing inner diameter options. It complies with European RoHS, REACH regulations and holds CE certification. Standard POM material delivers high rigidity and high strength, maintaining stable performance after 100,000 connect‑disconnect cycles. Custom body materials including PP, PC and POK are available.

Specifications:

Pressure: Vacuum to 120psi (0.8Mpa)

Temperature: ‑40℃ ~ 100℃

Materials:

Body & Valve Core: POM

Spring: 316 Stainless Steel

Seals: EPDM

Inner Diameter: 1/16" ~ 3/8" ID (1.6mm ~ 9.5mm ID)

Color: White as standard; other colors available upon custom request.

Customizable body materials: PP, PC, POK

Customizable seal materials: FKM, NBR, SIL, AFLAS, FFKM
