KSJ series are metal quick‑disconnect connectors, manufactured by CNC machining followed by chrome‑plating or passivation treatment. It features high surface hardness and excellent gloss. Male and female ends are locked by metal push‑buttons. Widely applied in corrosive and food‑processing environments. Customization per client requirements is a key advantage of the KSJ series.

Specifications:

Pressure: Vacuum to 145psi (1MPa)

Temperature: ‑40℃ ~ 200℃

Materials:

Body: Chrome‑plated copper alloy

Spring & Push‑button: Stainless steel

O‑ring: Peroxide‑cured EPDM (EPDM Pro)

Inner Diameter: 1/8" ~ 3/8" (3.2mm ~ 9.5mm)

Color: Bright silver

Customizable body material: Passivated stainless steel

Customizable seal materials: FKM, AFLAS, FFKM
