KSPC/QSC series adopts ferrule‑tube‑locking structure instead of traditional barbed barb‑tail design. It solves the difficulty of pulling out hoses after long‑time service. The ferrule‑locking mechanism maintains high tensile strength. Hoses can be released easily by pushing the ferrule, lowering operation difficulty, ideal for frequent hose plug‑and‑unplug applications.

Specifications:

Pressure: Vacuum to 100psi (0.7MPa)

Temperature: ‑40℃ ~ 100℃

Materials:

Body & Ferrule: POM

Spring & Gripper Claws: Stainless steel

O‑ring: EPDM, NBR

Outer Diameter: 1/2", 3/8", 1/4" OD

Color: White as standard; other colors available upon custom request.
